4. Securing the workpiece
WARNING: Always clamp or v ise to secure the workpiece to the fence; otherwise the workpiece
might be thrust from the table and cause bodily harm.
5. Installing the extension wings (Optional accessory)
The extension wings help keep longer w orkpieces stable and in
place during the cutting operation.
(1) Insert the 8 m m screw into the hole located on the base.
(2) Set the lock support rod under the side of the base.
(3) Then with the 8 m m screw for the lock support rod temporary
stop.
(4) Insert an extension wing into the two holes of the lock support
rod.
(5) Push an extension wing until it contact with the base.
(6) Fasten the 8 m m screw and fix an extension wing.
CAUTION: When transporting or carrying the tool, do not
grasp the extension wing.
There is the danger of the extension wing slipping
out of the base. Grasp the handle (see Fig. 1)
instead of th e extension wing.
6. Stock stop for precision cutting (Stock stop is optional accessory)
The stock stop facilitates continuous precision cutting
in lengths of 10" to 16-21/32" (253 m m to 423 m m). To
install the stock stop, attach it to the extension wing with
the 6 m m wing bolt as shown in Fig. 15.
PRACTICAL APPLICATIONS
WARNING: * To avoid personal inj ury, never remove or place a workpiece on the table while the tool
is being operated.
* Never p lac e your limbs inside o f the line ne xt to warning sign while the tool is being
operated. This may cause hazardous conditions (see Fig. 16).
Fig. 16
Extension
Wing
Fig. 13
Lock Support
Rod
Extension
Wing
Base
8 m m
Scre w
Extension Win g
6 m m W ing Bolt
Stock Stop
Warnin g Sign
