RS-232C Communication / Network command table
RS-232C Communication / Network command table
(continued on next page)
Names Operation Type Header
CRC
Command Data
Action Type Setting code
Power
Set
Turn off BE EF 03 06 00 2A D3 01 00 00 60 00 00
Turn on BE EF 03 06 00 BA D2 01 00 00 60 01 00
Get
BE EF 03 06 00 19 D3 02 00 00 60 00 00
[Example return]
00 00 01 00 02 00
[Off] [On] [Cool down]
Input Source
Set
COMPUTER IN1 BE EF 03 06 00 FE D2 01 00 00 20 00 00
COMPUTER IN2 BE EF 03 06 00 3E D0 01 00 00 20 04 00
LAN BE EF 03 06 00 CE D5 01 00 00 20 0B 00
USB TYPE A BE EF 03 06 00 5E D1 01 00 00 20 06 00
USB TYPE B BE EF 03 06 00 FE D7 01 00 00 20 0C 00
HDMI 1 BE EF 03 06 00 0E D2 01 00 00 20 03 00
HDMI 2 BE EF 03 06 00 6E D6 01 00 00 20 0D 00
COMPONENT BE EF 03 06 00 AE D1 01 00 00 20 05 00
S-VIDEO BE EF 03 06 00 9E D3 01 00 00 20 02 00
VIDEO BE EF 03 06 00 6E D3 01 00 00 20 01 00
Get BE EF 03 06 00 CD D2 02 00 00 20 00 00
Error Status
Get
BE EF 03 06 00 D9 D8 02 00 20 60 00 00
[Example return]
00 00 01 00 02 00 03 00
[Normal] [Cover error] [Fan error] [Lamp error]
04 00 05 00 07 00 08 00
[Temp error] [Air ow error] [Cold error] [Filter error]
FOCUS
Increment BE EF 03 06 00 6A 93 04 00 00 24 00 00
Decrement BE EF 03 06 00 BB 92 05 00 00 24 00 00
ZOOM
Increment BE EF 03 06 00 96 92 04 00 01 24 00 00
Decrement BE EF 03 06 00 47 93 05 00 01 24 00 00
LENS SHIFT - V
Increment BE EF 03 06 00 D2 92 04 00 02 24 00 00
Decrement BE EF 03 06 00 03 93 05 00 02 24 00 00
LENS SHIFT - H
Increment BE EF 03 06 00 2E 93 04 00 03 24 00 00
Decrement BE EF 03 06 00 FF 92 05 00 03 24 00 00
LENS SHIFT
CENTERING
Execute BE EF 03 06 00 B8 93 06 00 04 24 00 00
LENS MEMORY
INDEX
Set
1 BE EF 03 06 00 4B 92 01 00 07 24 00 00
2 BE EF 03 06 00 DB 93 01 00 07 24 01 00
3 BE EF 03 06 00 2B 93 01 00 07 24 02 00
Get BE EF 03 06 00 78 92 02 00 07 24 00 00
LENS MEMORY
LOAD
Execute BE EF 03 06 00 E8 90 06 00 08 24 00 00
LENS MEMORY
SAVE
Execute BE EF 03 06 00 14 91 06 00 09 24 00 00
LENS MEMORY
CLEAR
Execute BE EF 03 06 00 50 91 06 00 0A 24 00 00
