 Attachment 1 List of Mode Functions

● List of elevator mode functions
MODE Function (1) (2) (3) MODE Function (1) (2) (3)
0 (Return to normal indication) ○○○ 33Start compensation UP bias adjust ○○○
1 Hour meter indication ○○○ 34Start compensation DN bias adjust ○○○
2 Trouble monitor ○○○ 35Load detection 100% setting ○○○
3 Low speed operation in the machine room ○○ 36Start compensation UP gain adjust ○○○
4 Registers a car call for the button floor ○○ 37Start compensation DN gain adjust ○○○
5 Registers a car call for the middle floor ○○ 38Confined load detection value setting (UP) ○
6 Registers a car call for the any floor ○○ 39Confined load detection value setting (DN) ○
7 Registers a car call for the top floor ○○ 3C20% load torque value setting ○
9 Data Tracer supplementary data indication, clear ○ 3D80% load torque value setting ○
B Earthquake control operation simulation ○○ 3EHigh speed travel frequency indication ○○
C Fire control operation simulation ○○ 40Operating system code indication ○○○
D Flood evacuation operation simulation ○○ 42Earthquake emergency operation reset (UA2) ○○
E 110%-loaded operation simulation ○○ 43Compensates the micro-running speed gain (HVF) ○○
F 110%-loaded buzzer enabled operation ○○ 44Maximum speed limit ○
11 Operation for measuring the height of a story
○○○
45 Compensates the deceleration of the rescue
operation speed (HVF)
○○
12 Digital Indicator checking ○○ 46Start compensation rope weight correction ○○
13 100% loading detection cut, based on the Labor
Safety and Health Law
○○○
4C Stop position correction
○○
14 SDS test ○ 4DMicro-running speed adjust (UA2) ○○
15 Independent operation ○○ 52One-story running level adjust ○○○
16 Micro-leveling operation cut ○○ 53Stop position adjust data change (UP) ○○○
17 Test of instantaneous roll type safeties for
government (torque up)
○
54 Stop position adjust data change (DN)
○○○
18 Slave constant INV microcomputer transmission ○○ 57Brake torque test mode ○○
19 Regenerative PAM separation mode (UA03) ○ 58Magnetic pole offset auto-tuning ○
1B Digital display under inspection indication ○○ 62Group control admission monitor ○○
1C ALP abnormal reset ○○○ 65Stationary motor current indication ○
1D SDS (D) ON failure cut ○ 66Motor current indication ○
1E Micro-leveling operation set ○○ 67Motor current gain set ○
1F Common spec. master/slave transfer (UA1) ○ 68Magnetic pole sensor offset adjust (UA2) ○
20 Trouble indication selection ○○ 69Motor current detect offset adjust, UA2 ○
21 Car call hold type selection ○○ 6AMotor current detect gain adjust, UA2 ○
22 Master microcomputer memory R/W (1W) ○○ 70Master microcomputer memory R/W (DPRAM, 1B) ○
23 Slave microcomputer memory R/W (1W) ○○ 71Slave microcomputer memory R/W (DPRAM, 1B) ○
24 Hour meter rewrite ○○ 72Master microcomputer memory R/W (DPRAM, 1W) ○
26 Load indication (%) ○○○ 73Slave microcomputer memory R/W (DPRAM, 1W) ○
27 Speed indication (m/min) ○○○ 74Master microcomputer memory R/W (DPRAM, 1L) ○
28 Adjusts the very low speed time on the bottom floor ○○ 75Slave microcomputer memory R/W (DPRAM, 1L) ○
2A Main circuit voltage indication (HVF) ○ 76Master microcomputer memory R/W (1L), CPU reset ○○
30 Master microcomputer memory R/W (1 byte, bit) ○○ 77Slave microcomputer memory R/W (1L) ○
31 Slave microcomputer memory R/W (1 byte, bit) ○○ 7EMicrocomputer loading rate indication (%) ○
32 Load detection zero-point setting ○○○  
(1): EC2-605, (2): EC3-605, (3): EC4-605
● List of escalator mode functions (Applicable to EC4-605 only)
MODE Function MODE Function MODE Function
0 (Return to normal indication)22Master microcomputer memory R/W (1W)40Operation system code indication
1 Hour meter indication23Slave microcomputer memory R/W (1W)51Low-speed operation length of time for considerate
operation
2 Trouble monitor24Hour meter rewrite52Automatic operation time R/W
6 Maintenance operation speed set27Speed indication (m/min)53Lower stop position adjust spec. write
8 Starting frequency indication28Hand rail travel speed (L)54Automatic lubricate interval time R/W
9 Tracer supplementary data indication, clear29Hand rail travel speed55Y-∆ connection spec. select time R/W
10 Clock data acquisition (HERIOS)2AStarting frequency rewrite56Unloaded crawling operation time R/W
11 Switch pitch measuring operation2ESpeed indication (Motor R. E.)60Meitetsu-spec. automatic operation timer adjust
12 Lubrication pump operation2FSpeed indication (Decelerator R. E.)61Meitetsu-spec. automatic operation timer adjust
13 Electric operation reset30Master microcomputer memory R/W (1 byte, bit)62Meitetsu-spec. automatic operation timer adjust
14 Start enabled chec
k
31Slave microcomputer memory R/W (1 byte, bit)63Meitetsu-spec. automatic operation timer adjust
15 Wheel chair startup maintenance enabled36Wheel chair operation frequency70Master microcomputer memory R/W (DPRAM, 1B)
18 Constant INV microcomputer transmission37Operation frequency (for Lonworks)71Slave microcomputer memory R/W (DPRAM, 1B)
19 Reflex type sensor adjust mode38UP operation frequency (for Lonworks)73Writing of local adjustment area enable
20 Trouble indication select39DN operation frequency (for Lonworks)75Program ROM rewrite
For further details, refer to the Technical Comment for Installation and Maintenance of respective machine types.

