4.3 INSTALLATION SPACE (LOCATION, PRECAUTION, CONDITIONS & ORDER)
! DANGER
• Donotinstalltheindoorunitsoutdoors.Ifinstalledoutdoors,an
electrichazardorelectricleakagewilloccur.
• Considertheairdistributionfromeachindoorunittothespace
oftheroom,andselectasuitablelocationsothatuniformair
temperatureintheroomcanbeobtained.
• Avoid obstacles which may hamper the air intake or the air
dischargeow.
• Payattentiontothefollowingpointswhentheindoorunitsare
installedinahospitalorotherplaceswherethereareelectronic
wavesfrommedicalequipment,etc.
- Donotinstalltheindoorunitswhereelectromagneticwaveis
directlyradiatedtotheelectricalbox,remotecontrolcable
orremotecontrolswitch.
- Installtheindoorunitsandcomponentsasfaraspracticalor
atleast3metersfromtheelectromagneticwaveradiator.
- Prepareasteelboxandinstalltheremotecontrolswitchinit.
Prepareasteelconduittubeandwiretheremotecontrolcable
init.Thenconnectthegroundwirewiththeboxandtube.
- Installanoiselterwhenthepowersupplyemitsharmful
noises.
- Donotinstalltheindoorunits,outdoorunit,remotecontrol
switchandcablewithinapproximately3metersofstrong
electromagneticwaveradiatorssuchasmedicalequipment.
• Thisunitisexclusivenonelectricalheatertypeindoorunit.Itis
prohibitedtoinstallaelectricalheaterintheeld.
• Donotputanyforeignmaterialintotheindoorunitandcheckto
ensurethatnoneexistintheindoorunitbeforetheinstallation
andtestrunning.Otherwiseareorfailure,etc.,mayoccur.
• Donotperforminstallationwork,refrigerantpipingwork,drain
pumping, drain piping and electrical wiring connecting work
withoutreferring to theinstallationmanual. Iftheinstructions
are not followed, it may result in a water leakage, an electric
shock,areandaninjury.
• Mount suspension bolts using M10 (W3/8) as size, as shown
below:
Concrete
Wooden
Beam
Nuts
Square
washers
Sling Bolt
(W3/8 or M10)
Anchor Bolt
Steel
Suspension Bolts
(W3/8 or M10)
For Concrete Slab
150~160mm
Wooden Bar
(60mm to 90mm Square)
I-Beam
! CAUTION
• Do not install the indoor units in a ammable environment to avoid a
re or an explosion.
• Check to ensure that the ceiling slab is strong enough. If not strong
enough, the indoor unit may fall down on you.
• Do not install the indoor units in a machinery shop or kitchen where
vapor from oil or mist ows to the indoor units. The oil will deposit on
the heat exchanger, thereby reducing the indoor unit performance,
and may deform. In the worst case, the oil damages the plastic parts
of the indoor unit.
• To avoid any corrosive action to the heat exchangers, do not install
the indoor units in an acid or alkaline environment.
• When lifting or moving the indoor unit, use appropriate slings to avoid
damage and be careful not to damage the insulation material on units
surface.
4.3.1 Suspended unit
Install the indoor unit with a proper clearance around it paying
careful attention of installation direction for the piping, wiring and
maintenance working space.
Mount suspension bolts using M10 (W3/8) or greater are also
recommended, as size, as shown below:
DIMENSIONS TO INSTALL SUSPENSION BOLT (mm)
Models a b
RPI-(1.5~2.0)FSRE 790 544
RPI-(2.5~3.0)FSRE 1124 544
RPI-(4.0~6.0)FSRE 1514 544
For concrete slab:
Anchor bolt
(W3/8 or M10)
Concrete
Steel
150 to 160mm
Insert
(100 to 150kg)
For steel beam:
I-Beam
Suspension bolt
(W3/8 or M10)
INDOOR UNITS INSTALLATION
PMML0528 rev.1 - 02/2021
