RPI-(2.0-6.0)FSN2E. Terminal board connections
Nº
Part
PCB1 Printed circuit board.
TF Transformer.
TB Terminal strip.
RPI-(8.0/10.0)FSN2E Terminal board connections
4 Electrical wiring
124
SMGB0063 rev. 1 - 10/2010
