Number Part name Remarks
U00 Printed circuit board terminals
U02 Electrical box Assembly of (components + harness)
U14 Capacitor 4uF/5uF
U15A Thermistor THM3 thermistor for liquid piping
U15B Thermistor THM5 thermistor for gas pipe
U15C Thermistor THM1 thermistor for air inlet
U15D Thermistor THM2 thermistor for air outlet
U21 Expansion valve —
U31 Air filter —
U33 Bearing —
U34A Air inlet grille Inlet air
U34B Grille assembly A Outlet air
U34B Grille assembly B Outlet air
U34B Grille assembly C Outlet air
U37 Fan frame —
U41 Heat exchanger Assembly
U64 Heat exchanger Assembly
U64 Boss —
U65A Spacer —
U65B Push spacer —
U65C Grille knob
U65D Grille support
U71A Fan motor —
U71B AS motor —
U82 Transformer —
U85 Printed circuit board -
U98A Left cover Left part
U98B Right cover Right part
U98C Lower cover assembly Lower part
U98D Upper cover assembly Upper part
9 Spare parts
245
SMGB0063 rev. 1 - 10/2010
