Number Part name Remarks
U00 Printed circuit board terminals —
U02 Remote control PC-ART (optional)
U13 Electrical box Assembly of (components + harness)
U14 Capacitor 3.15uF/4uf
U15A Thermistor For the liquid piping
U15B Thermistor For the gas pipe
U15C Thermistor For the air inlet
U15D Thermistor For the air outlet
U21 Expansion valve —
U31 Filter —
U36 Runner —
U37 Fan frame —
U41 Heat exchanger Assembly
U65A Spacer For the fixed PCB
U65B Push spacer For the fixed PCB
U71A Drain pump Discharge mechanism
U71B Fan motor —
U82 Transformer —
U85 Printed circuit board PI073 (main PCB)
U87 Float sensor —
U97 Drain pan Assembly
9 Spare parts
247
SMGB0063 rev. 1 - 10/2010
9
