Number Part name Remarks
U02 Remote control PC-LH3 (optional)
U04A Fuse 5A (for unit control)
U15A Thermistor THM1 thermistor for air inlet
U15B Thermistor THM2 thermistor for air outlet
U15C Thermistor THM3 thermistor for protection against liquid freezing.
U15D Thermistor THM5 thermistor for gas
U21 Expansion valve —
U31A Right air filter For right part
U31B Left air filter For left part
U33 Bearing —
U36 Fan —
U41 Heat exchanger —
U71A Fan motor Expansion valve
U71B AS motor 20W fan
U71C Motor —
U85A Printed circuit board Power
U85B Printed circuit board Control
U85C Printed circuit board Receiver
U85D Printed circuit board Service
9 Spare parts
