Hitachi SJ300 Series

28
●General Specifications
SJ-DN has DeviceNet™ functions, and it can perform network communication such as RUN/STOP,
status monitoring, parameter setting, etc. by connecting with an upper level controller.
Expensive hard-wiring can be eliminated for space saving and cost reduction, and installation/
replacement within the system can be easily done.
●Specifications
●Dimensional drawings
No
1
Signal
Cable color
2
3
4
5
V
-
CAN_L
Drain
CAN_H
V+
Black
Blue
ー
White
Red
Note: Communication power supply (24VDC)
is required in system configuration.
●Cable connection
20.32
25.4
5.08
2.54
Black
8.3
15
18.2
Blue White Red
Nameplate
Item
Speed control
Specification
Position control
Orientation
Protective functions
Encoder feedback
Speed control method
Positioning command
Electronic gear
Stop position
Speed
Standard: 1024-pulse/r Maximum input pulse: 100k-pulse/s
Proportional-Integral
(
PI
)
/ Proportional
(
P
)
control
A-, B-phase, 90-degree phase difference input
(
By A-, B-, and Z-phase encoder), Maximum input pulse: 100k-pulse/s
Pulse ratioA/B
(
A,B:Settingrangeof1 - 9999
)
1/50≦A/B≦20
4096 splitting per motor's single revolution
(
Whenusingstandardencoder
)

Orientation speed and rotational direction can be set
Encoder cable disconnection protection, Over-speed protection, Positioning error
General data
Physical
conformance data
Communication data
Applicable DeviceNet specification
Vendor name
Device profile name
Network consumption current
Connector type
Isolation of physical layer
Support LED
MAC ID setting
Default MAC ID
Transmission baud rate setting
Support transmission baud rate
Pre-defined master/slave connection set
UCMM Support
Support connection
Explicit message fragmentation
Volume 1-Relesse 2.0 Volume 2-Relesse 2.0
Hitachi, Ltd. Vendor ID=74
Slave DC Drive Profile No.=13
50mA
Open connector
Ye s
Module status / network status
63
By digital operator
By digital operator
125k/250k/500k
Group 2 only server
None
Explicit message connection, Polled I/O connection
Ye s
[Unit:mm]
DeviceNet™ EXPANSION CARD
SJ-DN
DeviceNet is a trademark of Open DeviceNet Vendor Association.
