About the configuration file
The conguration information is stored with the following default le name:
■
If the box code is not entered, the le name consists of the controller box name
selected in the Array Unit Type dialog box with the extension .csv.
■
When the box code is entered, the le name consists of the controller box name
selected in the Array Unit Type dialog box, plus an underscore, plus the box code (up
to eight alphanumeric characters), with the extension .csv.
Observe the following guidelines when saving a conguration le:
■
If you save the conguration information le while editing the conguration in the
Logical or Physical conguration gure, the le is saved with the array unit
conguration unchanged.
Observe the following guidelines when loading a conguration le:
■
If you click Reset after editing a loaded conguration information le, the previous
conguration gure screen is recovered.
■
If you load the conguration information le that was saved while editing the
conguration in the Logical or Physical conguration gure, the array unit
conguration displayed in the Logical or Physical conguration gure is unchanged.
Loading a configuration file
Procedure
1. In the conguration screen, click Load.
The Open dialog box opens.
2. In the Open dialog box, go to the folder that contains the conguration le you
want to load.
3. Click the conguration le, and then click Open.
The conguration information contained in the le is displayed in the BECK tool.
BECK tool messages
Message Corrective action
DBL has more rack-mountable
numbers than allowed.
Re-examine the unit congur
ation.
Display the Select Box dialog box and
delete the LFF.
DBS has more rack-mountable
numbers than allowed
Re-examine the unit conguration.
Display the Select Box dialog box and
delete the SFF.
About the congur
ation le
Chapter 1: Installation site considerations
Site Preparation Guide for VSP G/F350, G/F370, G/F700, G/F900 33
