Hitachi Virtual Storage Platform F350 Site Preparation Guide

Table 3 CBL and physical SVP
Component Drive trays Weight
CBL 48 SFF drive trays 2829 kg
(6236.9 lbs)
CBL 48 LFF drive trays 2810 kg
(6195 lbs)
CBL 48 FMD drive trays 3251 kg
7167.2 lbs
CBL 24 dense intermix drive trays 3717 kg
(8194.6 lbs)
Physical SVP N/A 4.5 kg
(10 lbs)
Non-Hitachi rack support
The storage system supports non-Hitachi racks that meet Hitachi specications.
Observe the following mounting guidelines for non-Hitachi racks:
■
The VSP Gx00 models VSP Fx00 models support any 4-post, EIA-310-D compliant rack
that has adequate airow and weight capacity.
■
PDUs must be mounted properly to avoid any issues while servicing the storage
system. The PDU receptacles must face toward the back (not toward each other). The
area behind the storage system and between the vertical 19-inch mounting posts
must be free of PDUs and cable loops.
Hitachi Universal V2 Rack rail kits
Use rail kits to mount the Hitachi Virtual Storage Platform family storage system in a
Hitachi Universal V2 Rack.
The following tables list the rail kit information for the specied storage systems.
Table 4 Rail kits for VSP Gx00 models VSP Fx00 models
Rail kit Hitachi Universal V2 Rack Third-party rack
Controller UNI
1
UNI
1
DBS, DBL, and DBF drive
tr
ays
CGR
2
UNI
1
Non-Hitachi rack support
Chapter 1: Installation site considerations
Site Preparation Guide for VSP G/F350, G/F370, G/F700, G/F900 41
