Charger Operations Continued
R shows the number of cells detected by the charger and S is the
number of cells set by you at the previous screen. If both numbers are
identical, press START/ENTER to start the charging process.
If the user charges two batterries simultaneously, this screen will
display after the twin-channels have been working for 10 seconds.
The user can push the channel button to view the full charge status of
either A or B port.
Charging Status Monitor
During the charge process, the real-time status will be shown on screen.
R:3SER S:3SSER
Confirm (Enter)
91% 12.14V
1.5A 00:50:12
START/ENTER
A: 25% BAL
B:NiMH 6.3V CHG
←←
Real-time status: battery icon, percentage of charge, charge current,
battery voltage, elapsed time & capacity.
Voltage of each cell in the battery pack when the battery is connected
with the balance lead.
Final voltage when program ends.
Saftey timer ON and duration of time in minutes.
Capacity cut-o ON and the setting value capacity is
displayed.
91% 12.14V
1.5A 00:50:12
91% 12.14V
1.5A 00103mAh
LiPo BALANCE
2.0A 11.1v (3s)
4.070 4.060V
4.110 0.000V
Safety Timer
ON 120 Min
Capacity Cut-Off
ON 5000mAh
←←
INC ►
INC ►
DEC
DEC
DEC
◄
◄
◄
End Voltage
12.6V(3S)
← ←
←←
To Next Page
