Hitron CGN3 User’s Guide
DS Green, blinking The CGN3 is searching for a downstream
frequency on the CABLE connection.
Green, steady The CGN3 has successfully located and locked
onto a downstream frequency on the CABLE
connection.
Blue The CGN3 is engaged in channel bonding on the
downstream connection.
Off There is no downstream activity on the CABLE
connection.
US Green, blinking The CGN3 is searching for an upstream frequency
on the CABLE connection.
Green, steady The CGN3 has successfully located and locked
onto an upstream frequency on the CABLE
connection.
Blue The CGN3 is engaged in channel bonding on the
upstream connection.
Off There is no upstream activity on the CABLE
connection.
STATUS Blinking The CGN3’s cable modem is registering with the
service provider’s CMTS.
On The CGN3’s cable modem has successfully
registered with the service provider and is ready for
data transfer.
LAN Off No device is connected to one of the LAN ports.
Green, blinking A device is connected to one of the LAN ports via a
Fast Ethernet (100Mbps) link, and is transmitting or
receiving data.
Green, steady A device is connected to one of the LAN ports via a
Fast Ethernet (100Mbps) link, but is not transmitting
or receiving data.
Blue, blinking A device is connected to one of the LAN ports via a
Gigabit Ethernet (1000Mbps) link, and is
transmitting or receiving data.
Blue, steady A device is connected to one of the LAN ports via a
Gigabit Ethernet (1000Mbps) link, but is not
transmitting or receiving data.
Table 3: LEDs
