– 7 –
Fig. 7 Fig. 8
PROTECTION DU DISQUE
COUTEAU
INSPECTIONDUJOINTD'ÉTANCHÉITÉ(FIG.9)
L'intervalle recommandé entre les inspections de nettoyage et de désinfection ne doit pas dépasser six
mois pour les composants qui sont xés (tous les joints d'étanchéité dans les images).
Les inspections doivent être effectuées par le fabricant ou un agent de service autorisé.
AVERTISSEMENT
Latrancheusedoitêtreretiréeduservicejusqu'àsaréparationparlefabricant
ouunagentdeserviceautorisésiunjointoujointd'étanchéitéestendommagéoumanquant.
PROTECTION SUR
L'INTERRUPTEUR
JOINT ENTRE LA TABLE
DE PRODUIT ET LE
GARDE-POUCE
JOINT ENTRE LA TABLE DE
PRODUIT ET LA RALLONGE
JOINT ENTRE LA TABLE
DE PRODUIT ET LE
SUPPORT
JOINT ENTRE LA POIGNÉE
ET LE SUPOORT DE TABLE
À PRODUIT
JOINT D'ÉTANCHÉITÉ ENTRE LA
POIGNÉE/ENTRETOISE ET
L'ENTRETOISE/POUSSOIR
À VIANDE
Fig.9
