Hobart Handler 135 User Manual

OM-944 Page 38
SECTION 8 – PARTS LIST
. Hardware is common and
not available unless listed.
802 449-B
3
4
9
8
32
35
13
5
34
33
11
12
24
26
2
17
6
18
10
38
37
42
1
31
14
16
36
29
30
15
27
28
41
25
23
22
19
21
20
7
39
40
47
46
45
44
43
48
49
50
51
Figure 8-1. Main Assembly

Hobart Handler 135 Specifications

General

Amperage Output	25-135A
Wire Feed Speed	40-700 IPM
Input Current	20A
Output Current Range	25 - 135 A
Welding Processes	MIG (GMAW)
Maximum Material Thickness	1/4 inch
Input Frequency	60 Hz
Wire Size Range	0.023-0.035 inch
Input Phase	Single Phase
