Discovery QDR Series Technical Manual

5-43

Table 5-4. Lower C-Arm FRUs (Figure 5-7)

Table 5-5. Upper C-Arm FRUs (Figure 5-9 and Figure 5-10)

Table 5-6. Computer and Isolation Module

Part Number Description Used On

010-0575 X-ray Tank All

010-1547 Aperture/Filter Drum Assembly Ci, Wi

010-1549 Aperture/Filter Drum Assembly C, W, SL, A

ASY-000409 Assy, 10ma X-Ray Controller All

140-0090 C-arm Interface Board All

Part Number Description Used On

010-0682 Assy, Crosshair Laser Block All

030-3171 Control Panel, Discovery, 7 Button C and W

030-3127 Control Panel, Discovery, 9 Button A and SL

465-0042 Switch, Pushbutton w/LED Pnl All

465-0043 Switch, Emergency Stop Anti-Rotate All

ASY-01374 128 Channel Assy 56303 C, W, SL

010-1606 Assy, Discovery Det 216 Chan 2mm A

010-1653 64 Channel Detector Assembly Ci, Wi

ASY-00271 64 Channel Detector Assembly Newer Ci, Wi

and

replacement

for 010-1653

on older Ci,

140-0087 A/D Converter PCB Ci/Wi with

010-1653

detector

Part Number Description Used On

PWR-100-DISCRY Kit, Power, Discovery, 100V All

PWR-120-DISCRY Kit, Power, Discovery, 120V All

PWR-230-DISCRY Kit, Power, Discovery, 230V All

010-1559 Assembly, Torroid All

120-0049 Monitor, 17" SVGA All

120-0152 Mouse, P/S All

120-0161 Keyboard, P/S All

010-1545 Discovery Computer w/XP All
