Discovery QDR Series Technical Manual
9-10
9.3 SQVERIFY
The SQVERIFY program is accessed from the Discovery Main Menu by selecting
Utilities|Service Utilities|SQVERIFY. This program is a diagnostic program, which
can be used to perform a series of low-level tests of system components. Refer to the
SQCHECK User Manual (080-0707) for detailed explanations of its use.
9.4 SQKEYPAD
The SQKEYPAD program is accessed from the Discovery Main Menu by selecting
Utilities|Emergency Motion. This program provides the Field Service Engineer with a
method for moving all motors even in conditions where a detected software error
condition would normally prevent any movement of the motors. This program can be used
as a quick means of checking most motor control functions.
