Discovery QDR Series Technical Manual
3-43
The program moves the TZ table to its top most position and moves the TX table
inwards until it almost touches the C-arm. It rotates the C-arm by 2 degrees to
obtain an initial estimate of the encoder calibration and then prompts:
The program rotates the C-arm counter clockwise (i.e., the tank assembly moves
away from the front of the machine). When the C-arm hits the AP mechanical
limit the first time, press <ESC>.
8. Check the position value. It must be 250±5. Adjust if necessary.
If out of range, loosen the coupling setscrew and manually rotate the encoder
until the readback is 250±5 (i.e., in the range 245-255) and then tighten the
coupling setscrew.
9. Before repeating the calibration procedure, rotate the C-arm back to approxi-
mately 0º by:
Typing the command: MOVE_REL 1470<Enter>.
10. Repeat the calibration procedure above but now, when AY hits the left mechani-
cal stop, press <Enter>.
Wait until the rotation completes and then repeat the calibration procedure above
but now, when the C-arm hits the AP mechanical stop,
11. Press <Enter>.
The program prompts:
and moves the C-arm back to the approximate 0° position. The program then
prompts:
Place a level on top of the X-ray tank assembly (not the top of the C-arm) and
use the Table IN/OUT switch on the operator panel to move the C-arm until it is
0º ±0.1º. Remove the level, wait until the rotation completes, and then repeat the
calibration procedure above but now, when the C-arm hits the AP mechanical
stop,
Press <Enter> when the AR motor reaches the AP mechanical limit.
Press <ESC> to stop calibration.
Press <ESC> to stop calibration. Press <Enter> when the AR motor
reaches the AP mechanical limit.
Press <ESC> to stop calibration.
Use the Table IN / OUT switch to move the C-Arm to 0 degrees.
Press <Enter> when the C-Arm is positioned.
Press <ESC> to stop calibration.
