128
TECHNICAL INFORMATION
MODEL BF60A
Description
code
BBFJ
Type LHT LRT XRT
Overall length 33.5 in (851 mm) 30.6 in (777 mm)
Overall width 16.4 in (417 mm)
Overall height 55.0 in
(1,397 mm)
60.0 in
(1,524 mm)
Transom height
(when transom
angle is 12°)
20.5 in
(521 mm)
25.5 in
(648 mm)
Dry mass
[weight]*
254 lbs (115 kg) 243 lbs (110 kg) 256 lbs (116 kg)
Rated power 44.7 kW (60 HP)
Full throttle
range
5,000 – 6,000 rpm
Engine type 4 stroke OHC in-line 3 cylinder
Displacement
60.9 cu-in (998 cm
3
)
Spark plug gap 0.031 – 0.035 in (0.8 – 0.9 mm)
Steering control
system
Tiller handle
Outboard motor-mounted,
remote control
Starter system Electric starter
Ignition system Full transistor battery
Lubrication
system
Trochoid pump pressure lubrication
Specified oil Engine: API standard (SG, SH, SJ)
SAE/FC-W 10W-30
Gear case: API standard (GL-4) SAE 90
Hypoid gear oil
Oil capacity Engine: 2.7 US qt (2.6 L)
without oil filter change
2.9 US qt (2.7 L)
with oil filter change
Gear case: 0.45 US qt (0.43 L)
CARB star label ULTRA · LOW EMISSION
D.C. output 12V – 20A
Cooling system Water cooling with thermostat
Exhaust system Water exhaust
Spark plugs LMAR6C-9 (NGK)
Fuel pump Low pressure side: mechanical type
High pressure side: electrical type
Fuel Unleaded gasoline
(86 pump octane or higher)
Gear change Dog type (Forward-Neutral-Reverse)
Steering angle 50° right and left
Trim angle – 4° to 16° (when Transom angle is 12°)
Tilt up angle 60° (when Transom angle is 12°)
Transom angle 8°, 12°, 16°, 20°, 24°
* Without battery cable, with propeller
Honda outboard motors are power rated in accordance with NMMA procedures and using the ICOMIA standard 28/23.
Specifications
