26
CONTROLS AND FEATURES
LRT and XRT Types
(remote control)
For panel-mount or top-mount remote
control information, refer to the
instructions provided with the remote
control equipment.
Side-Mount Control Type
(optional equipment)
Ignition Switch
The ignition switch controls the
ignition system and the starter motor.
Turning the ignition switch key to the
START position operates the starter
motor. The key automatically returns
to the ON position when released
from the START position.
The ignition switch can be used to
start the engine only when the control
lever is in the N (neutral) position
(p. 56) and the emergency stop switch
clip is in the emergency stop switch.
Turning the ignition switch to the
OFF position stops the engine.
IGNITION
SWITCH
EMERGENCY STOP
SWITCH
SWITCH CLIP
START
ON
OFF
