Honda BF60A - Tilt Lock Lever; Engine Cover Latches

33
CONTROLS AND FEATURES
Tilt Lock Lever
The tilt lock lever is used to support
the outboard motor in the fully-raised
position.
When the boat is to be moored for a
long time, tilt the outboard motor up
as far as it will go. Then move the tilt
lock lever to the LOCK position, and
gently lower the outboard motor until
the lever contacts the stern bracket.
Engine Cover Latches
The engine cover latches fasten the
engine cover to the outboard motor.
TILT LOCK LEVER
FREE
LOCK
(front)
(rear)
ENGINE
COVER
LATCH
UNLATCH
FIX
ENGINE
COVER
LATCH
UNLATCH
FIX
