Honda BF75D - Page 88

87
STARTING THE ENGINE
9. Insert the clip at the end of the
emergency stop switch lanyard into
the emergency stop switch.
Attach the other end of the
emergency stop switch lanyard
securely to the operator.
The engine does not start unless the
clip is set on the emergency stop
switch.
(H type)
EMERGENCY
STOP SWITCH
STOP
EMERGENCY STOP
SWITCH LANYARD
EMERGENCY STOP
SWITCH CLIP
(R1 type)
EMERGENCY
STOP SWITCH
STOP
EMERGENCY
STOP SWITCH
LANYARD
EMERGENCY STOP
SWITCH CLIP
(R2, R3 types)
EMERGENCY
STOP SWITCH
STOP
EMERGENCY STOP
SWITCH LANYARD
EMERGENCY STOP
SWITCH CLIP
