Honda BFP8D - Specifications

118
TECHNICAL INFORMATION
Specifications
*1 With propeller
*2 Without charge coil
Honda outboard motors are power rated in accordance with NMMA procedures and using the ICOMIA standard 28/23.
MODEL BF8D/BFP8D
Description code BAAJ
Type H HS HT RT
Overall length 24.0 in (610 mm) 23.6 in (600 mm)
Overall width 13.6 in (345 mm)
Overall height S 43.5 in (1,105 mm)
L 48.6 in (1,235 mm)
X 54.1 in (1,375 mm)
Transom height
(when transom
angle at 12°)
S 17.0 in (433 mm)
L 22.2 in (563 mm)
X 27.7 in (703 mm)
Dry mass
[weight]
*1
S
89.3 lbs
*2
(40.5 kg)
–––
L
94.8 lbs
*2
(43.0 kg)
105.8 lbs
(48.0 kg)
123.5 lbs
(56.0 kg)
121.3 lbs
(55.0 kg)
X
–
114.6 lbs
(52.0 kg)
––
Rated power 6.0 kW (8 HP)
Full throttle range 4,500 – 5,500 rpm
Engine type 4 stroke OHC in-line 2 cylinder, water-cooled
Displacement
13.5 cu-in (222 cm
3
)
Starter system Recoil starter Recoil starter, Electric starter
Ignition system Digital ICM (Ignition Control Module)
Lubrication system Trochoid pump pressure lubrication
Specified oil Engine: API Service classification (SG , SH, SJ) SAE/FC-W 10W-30
Gear case: API Service classification (GL-4) SAE 90 Hypoid gear oil
31ZY06520.book Page 118 Friday, October 13, 2023 1:58 PM
