Honda BFP8D - Component and Control Locations

17
CONTROLS AND FEATURES
COMPONENT AND CONTROL LOCATIONS
H Type (tiller handle)
OIL FILLER CAP
OIL LEVEL
DIPSTICK
COOLING SYSTEM
INDICATOR
ENGINE OIL
DRAIN SCREW
ANODES
(each side)
MANUAL
RELIEF VALVE
(T type)
TILT LEVER
(manual tilt type)
TILLER HANDLE
GEARSHIFT LEVER
STARTER GRIP
STERN BRACKET
CLAMP SCREW
TRANSOM ANGLE
ADJUSTING ROD
GEAR OIL
LEVEL SCREW
COOLING WATER
INTAKE PORT
(each side)
GEAR OIL DRAIN/FILL SCREW
PROPELLER
EXHAUST PORT
ANTIVENTILATION
PLATE
FLUSH PORT HOLE
(inside engine cover)
ENGINE COVER
