TECHNICAL INFORMATION
Specifications
*1 With propeller
*2 Without charge coil
Honda outboard motors are power rated in accordance with NMMA procedures and using the ICOMIA standard 28/23.
MODEL BF9.9D/BFP9.9D
Description code BABJ
Type H HS HT R RT
Overall length 24.0 in (610 mm) 23.6 in (600 mm)
Overall width 13.6 in (345 mm)
Overall height S 43.5 in (1,105 mm)
L 48.6 in (1,235 mm)
X 54.1 in (1,375 mm)
Transom height
(when transom
angle at 12°)
S 17.0 in (433 mm)
L 22.2 in (563 mm)
X 27.7 in (703 mm)
Dry mass
[weight]
*1
S
89.3 lbs
*2
(40.5 kg)
100.3 lbs
(45.5 kg)
–––
L
94.8 lbs
*2
(43.0 kg)
105.8 lbs
(48.0 kg)
123.5 lbs
(56.0 kg)
106.9 lbs
(48.5 kg)
121.3 lbs
(55.0 kg)
X
103.6 lbs
*2
(47.0 kg)
114.6 lbs
(52.0 kg)
129.0 lbs
(58.5 kg)
–
126.8 lbs
(57.5 kg)
Rated power 7.4 kW (9.9 HP)
Full throttle range 5,000 – 6,000 rpm
Engine type 4 stroke OHC in-line 2 cylinder, water-cooled
Displacement
13.5 cu-in (222 cm
3
)
Starter system Recoil starter Recoil starter, Electric starter
Ignition system Digital ICM (Ignition Control Module)
Lubrication system Trochoid pump pressure lubrication
Specified oil Engine: API Service classification (SG, SH, SJ) SAE/FC-W 10W-30
Gear case: API Service classification (GL-4) SAE 90 Hypoid gear oil
