TECHNICAL INFORMATION
Specifications
*1 With propeller
*2 Without charge coil
*3 With charge coil
Honda outboard motors are power rated in accordance with NMMA procedures and using the ICOMIA standard 28/23.
MODEL BF15D/BFP15D
Description code BALJ
Type H HS HT RT
Overall length 25.6 in (650 mm) 25.2 in (640 mm)
Overall width 13.8 in (350 mm)
Overall height S 43.7 in (1,110 mm)
L 48.8 in (1,240 mm)
X 54.3 in (1,380 mm)
Transom height
(when transom
angle at 12°)
S 17.0 in (433 mm)
L 22.2 in (563 mm)
X 27.7 in (703 mm)
Dry mass
[weight]
*1
S
101.4 lbs
*2
(46.0 kg)
108.0 lbs
(49.0 kg)
126.8 lbs
(57.5 kg)
–
L
109.1 lbs
*3
(49.5 kg)
114.6 lbs
(52.0 kg)
131.2 lbs
(59.5 kg)
129.0 lbs
(58.5 kg)
X
––
136.7 lbs
(62.0 kg)
134.5 lbs
(61.0 kg)
Rated power 11.2 kW (15 HP)
Full throttle range 4,500 – 5,500 rpm
Engine type 4 stroke OHC in-line 2 cylinder, water-cooled
Displacement
21.4 cu-in (350 cm
3
)
Starter system Recoil starter Recoil starter, Electric starter
Ignition system Digital ICM (Ignition Control Module)
Lubrication system Trochoid pump pressure lubrication
Specified oil Engine: API Service classification (SG, SH, SJ) SAE/FC-W 10W-30
Gear case: API Service classification (GL-4) SAE 90 Hypoid gear oil
