INSTALLATION
To prepare the outboard motor for
connection to a battery, pull the cover
off the DC receptacle, connect the
battery charging wires to the plug.
Attach the plug to the receptacle on
the outboard motor.
The receptacle is provided with a
cover, which should be attached when
the plug is removed, in order to keep
the receptacle clean and dry.
Battery
For complete information, refer to the
battery manufacturer’s instructions.
Minimum Requirements
12V-35Ah (CCA 270)
Plug and Receptacle
(types without electric starter)
BATTERY
– TO ACCESSORIES
COVER
DC RECEPTACLE
– TO BATTERY
