are attached to these components.
WARNING
This vehicle has high voltage circuits and
parts. Failure to observe the following
precautions can result in burns or electric
shock.
●
Do not remove, disassemble, or replace
the high voltage parts, cables (orange) or
their connectors.
●
Never touch the High Voltage battery
service plugs.
In an emergency or during maintenance or
repair, the service plugs are removed to cut
off the electric flow from the battery. These
plugs are in contact with the battery and
can cause severe electric shock if not
handled properly.
Only a qualified technician should handle
any electrical equipment. For inspection
and repair, consult a dealer.
DC/DC Converter
A/C Compressor
d Charge Lid
High Voltage Battery
Label
a IPU Coolant Reserve Tank
Power Control Unit
Electric Motora IPU Coolant
Reserve Tank
b PCU Coolant Reserve Tank
c High Voltage Battery
Service Plug Lid
A/C Heater
c High Voltage
Battery Service Plug Lid
b PCU Coolant
Reserve Tank
d Charge Lid
To Next Page
