uuHonda Parking Pilot
*
u
538
The system can be used in the following situations:
*1:The parking space can be detected if there are three or more boundary lines and
enough spaces to park two or more vehicles.
Parking patterns
Parking spaces with
boundary lines
Parking spaces without
boundary lines
Reverse parking
Reverse angle parking
*1
—
1Honda Parking Pilot
*
For the front/side/rear cameras, refer to the following
page.
2 Camera Locations and Images P. 525
For directions on the proper handling of the sonar
sensors, refer to the following page.
2 Sonar Sensors P. 497
Do not use this system in unsuitable
locations
Do not use Honda Parking Pilot on slopes,
irregularly shaped parking spaces, and
other locations where it is not suited for
use.
2 Unsuitable Locations for System Use
P. 540
* Not available on all models
