uuFusesuFuse Locations
Continued
Handling the Unexpected
■
Circuit protected and fuse rating
Circuit Protected Amps
1
FUSE BOX SUB 40 A
ESB 40 A
ABS/VSA FSR 40 A
RELAY MODULE 1 30 A
IG MAIN 2 30 A
IG MAIN 30 A
MAIN FUSE 150 A
2
EPS 70 A
FUSE BOX MAIN 2 50 A
ABS/VSA MOTOR 40 A
COOLING FAN 60 A
FUSE BOX OPTION 2 50 A
RELAY MODULE 2 30 A
3
R/BOX MAIN 1 40 A
FRONT DEICER RIGHT
*
30 A
– –
FUSE BOX OPTION 1 40 A
FUSE BOX MAIN 1 40 A
BLOWER MOTOR 40 A
4
POWER WINDOW MAIN 1 60 A
POWER WINDOW MAIN 2 60 A
REAR DEFROSTER 40 A
FRONT DEICER LEFT
*
30 A
5 COOLING FAN CONTROL 5 A
6 WIPER 30 A
Circuit Protected Amps
7 STOP LIGHTS 10 A
8 IGA 10 A
9 IGB 10 A
10 BACK UP P/P 10 A
11
DT ELECTRIC WATER
PUMP 2
10 A
12 – –
13 HEAD LIGHT CONTROL LEFT 10 A
14
HEAD LIGHT CONTROL
RIGHT
10 A
15 DT ELECTRIC WATER PUMP 15 A
16 BATTERY SENSOR 7.5 A
17 IGMG ECU 7.5 A
18 BACK UP 10 A
19 AUDIO 15 A
20 WASHER 15 A
21 ES VLV1 7.5 A
22 ES VLV2 7.5 A
23 HORN 10 A
24
ES ELECTRIC COOLANT
HEATER
10 A
25 ES ELECTRIC WATER PUMP 10 A
26 FRONT FOG LIGHT 15 A
27 CHARGE LID ACTUATOR 10 A
* Not available on all models
