666
uuFusesuFuse Locations
Handling the Unexpected
■
Circuit protected and fuse rating
Circuit Protected Amps
1 – –
2 LEFT SIDE DOOR UNLOCK 10 A
3 RIGHT SIDE DOOR UNLOCK 10 A
4 ACC 10 A
5 – –
6 SRS 10 A
7 – –
8 P-ACT ECU 7.5 A
9 KEYLESS ACCESS 10 A
10 REAR FOG 10 A
11 LEFT SIDE DOOR LOCK 10 A
12 – –
13 RIGHT SIDE DOOR LOCK 10 A
14 OPTION 10 A
15 DAYTIME RUNNING LIGHT 5 A
16 – –
17 WIDE MONITOR 10 A
18 HAZARD 10 A
19
CENTRE CAMERA MIRROR
SYSTEM
7.5 A
20
QUICK CHARGEING
SYSTEM
10 A
Circuit Protected Amps
21 – –
22 – –
23 COMBO 10 A
24 IMG 10 A
25 SHIFTER 7.5 A
26
LEFT SIDE CAMERA MIRROR
SYSTEM
10 A
27
RIGHT SIDE CAMERA
MIRROR SYSTEM
10 A
28 ABS/VSA 7.5 A
29 ELECTRIC POWER PLANT 7.5 A
30 – –
31 REAR USB CHARGER 10 A
32 OPTION 10 A
33 – –
34 FRONT SEAT HEATERS 20 A
35 ACG 10 A
36 METER 10 A
37 OPTION 10 A
38 – –
39 – –
40 HEATED STEERING WHEEL
*
10 A
Circuit Protected Amps
41 IGC 10 A
42 – –
43 AUDIO SUB 7.5 A
44 PREMIUM AMP
*
20 A
45 REAR WIPER 10 A
46 SRS 10 A
47 – –
48 A/C MAIN 10 A
49 DOOR LOCK 20 A
50
FRONT ACCESSORY
SOCKET
20 A
51 – –
52
A/C ELECTRIC WATER
PUMP
10 A
53 SUPER LOCK
*
20 A
54
POPUP DOOR OUTER
HANDLE
15 A
55 – –
* Not available on all models
