44
Checking the system
Test start points
You can check whether the lawn mower can correctly return to the docking
station, and whether it can reach each start points according to settings.
Home screen J [3.Diagnostics] J [2.Test start points] J
[1.Point1] to [5.Point5]
You can test if the lawn mower will correctly go to a
specifi c start point.
HRM310: Start point 1 to 3
HRM520: Start point 1 to 5
NOTE:
- Perform this test when the lawn mower is
connected to the docking station.
1
Select a point from 1 to 5 which you want to
test and press the H button.
2
Confi rm the value of the selected point
settings.
3
Select [Yes] and press the H button.
4
Close the control panel cover.
The lawn mower starts to the selected start point.
When the test is correctly fi nished, the lawn
mower rolls slowly from side to side showing the
minimum and maximum exit angle, and a beep
sound is emitted from the lawn mower.
5
Press the manual STOP button.
The control panel cover pops up.
The message “Do you want to modify the start
point?” appears on the display.
6
Select [Yes] or [No] to the question and press
H button.
If you select [Yes], Mowing start point screen
appears. You can modify the settings of the
tested start point.
If you select [No], the previous screen appears.
NOTE:
- For details on the start point settings, see
“Setting the mowing start points” (M page
19).
Menu screen
