104 CT40/CT40 XP Mobile Computer Series User Guide
N6700 Imager/N6703 Imager Field of View/Resolution
DPI can be calculated based on the following formula:
Horizontal DPI = 1280 pixels/width of horizontal field of view (inches)
Vertical DPI = 800 pixels/width of vertical field of view (inches)
S0703 2D Imager
The depth of field measurements used the following parameters:
• Distances are measured from the front of the Imager.
• +23°C (+73°F), 0 lux for guaranteed, 200 lux for typical.
• Photographic quality codes
Note: Time to Read and Depth of Field will be impacted if the barcode symbol is at the edge
of the image.
Guaranteed Specs
Focus Standard Range (SR)
Horizontal Field Angle (degrees) 48 ± 2°
Vertical Field Angle (degrees) 31 ± 2°
Focus Standard Range
Symbology Near Distance Far Distance
5 mils Code 39 mm 79 270
in. 3.11 10.63
10 mils Code 39 mm 40 425
in. 1.57 16.73
20 mils Code 39 mm 44 674
in. 1.73 26.53
13 mils UPC-A mm 44 493
in. 1.73 19.41
15 mils Code 128 mm 42 572
in. 1.65 22.52
10 mils Data Matrix mm 83 236
in. 3.27 9.29
6.7 mils PDF417 mm 96 236
in. 3.78 9.29
1
Minimum distance depends on the length of the barcode.
2
Typical code wide to narrow elemental ratio is 3:1. Minimum 100 mils code height of 3 inches.

Honeywell CT40 Specifications

General

Processor	2.2 GHz Qualcomm Snapdragon 660 octa-core
Operating System	Android
Display	5-inch, 1280 x 720 HD, LED backlight
RAM	2 GB
Storage	16 GB
Camera	13 MP autofocus with LED flash
Battery	4000 mAh
Connectivity	Wi-Fi 802.11 a/b/g/n/ac, Bluetooth 4.2, NFC
Durability	IP64 rated
Drop Specification	1.2m (4ft) to concrete, 1.8m (6ft) with rubber boot
Barcode Scanning	1D/2D imager
Operating Temperature	-20°C to +50°C (-4°F to +122°F)
GPS	Yes
Weight	278 g (with battery)
