3. OPERATION
active _ inactive . = missing
AL = mnemonic for alarm
RL = mnemonic for relay
AN = mnemonic for analog input
MA = mnemonic for maths results
CO = mnemonic for comm. Channels
• SPEED IN USE
In the trend mode, speed number, value and unit will be displayed.
SP 1 or SP 2 = mnemonic for speed 1 or speed 2
In tabular mode, interval name, time and unit will be displayed.
INT1 or INT2 = mnemonic for interval 1 or interval 2
• DATE AND TIME
Day, month, year, hour "h" and minutes will be displayed.
AL 0 4 - RL 0 6 _ - AN 1 1
AL 0 4 - RL 0 6 _ - MA 1 2
AL 0 4 - RL 0 6 _ - CO 0 1
SP 1 1 5 0mm / h
INT 1 1 0 m i n
2 5 FEB 9 6 1 1 h 1 3
