3-7
3. OPERATION
3.4.3.2 Exception: For selections on the 2 displays with the same display type
In this case the upper display shows odd numbers and the lower one shows even numbers.
For example:
If a channel is not configured or does not exist, when previous or next channel is correct, then display mode
and channel number are only displayed. See the examples below:
Only channel 01 is not correct:
Only channel 06 is not correct:
LOCK displays
In this case you are allowed to select a display mode only in the upper display.
• MATHS RESULTS
The upper display shows the tag name.
The lower display shows value and unit of maths results.
To display maths results, the maths option is required.
AN 0 1 1 2 4 . 2
o
C
AN 0 2 5 4 4 . 7
o
C
AN 0 1
AN 0 2 1 4 . 1
o
C
AN 0 5 7 4 . 3
o
C
AN 0 6
MA 2 0 TAG NAME
1 . 3 2 E + 1 2 UNITS
