E-MON CLASS 3200 METER
37 62-0397—02
Fig. 27. Push Buttons.
10.3 How to Program the Display Screens
The display information can be programed using four push buttons switches. The
push buttons (DOWN, UP, SELECT, MENU) are located at the bottom of the
display board on the inside front door of the meter. The buttons are used to
program the following:
• Date & Time (This field sets the month, day, year, and time.)
• Device ID (This field changes the default setting, which is 1A for EZ7 and 1 for
ModBus.)
• Reset KW/KWH Read (This field resets the Peak kW Demand to zero.)
62-0397_C.fm Page 37 Wednesday, May 9, 2018 9:28 AM
