Honeywell E-Mon Class 3200 User Manual

E-MON CLASS 3200 METER
7 62-0397—02
3.0 METER TECHNICAL SPECIFICATIONS
Ordering Information: Define brand, class, input voltage, amperage, protocol, and
sensor type in the format A-BB-CCC-DDDD-E-FFF-GGG, where:
A = Brand: E for Honeywell E-Mon
BB = designates Class 3200 (32), or Class 5000 (50) meter
CCC = input voltage: (208, 400, 480, 600, 120 volt for High Voltage)
DDDD = current rating: (100, 200, 400, 800, 1600, 3200, 25HV)
E = enclosure: J = metal (type 1), R = non-metallic (rain tight) (type 4X), M = MMU
FFF= protocol: RTU = Modbus, BAC = BACnet, EZ7 = proprietary
“-SP”= Single or Two Phase
GGG = Sensors: KIT = split-core, SCS = solid-core, “blank” = none supplied
Brand Class Voltage Amperage Enclosure Communication Protocol Current Sensor/Option Current Sensor/Option Current Sensor/Option
Example E 32- 208 100- J RTU KIT
E32-208100-JRTUKIT
Brand E for Honeywell E-Mon
Class 3200
Voltage 120, 208, 400 (380-415), 480, 600
Amperage 2HV, 100, 200, 400, 800, 1600, 3200
Enclosure J (JIC Steel), I (Interior only), M (MMU Style), R (Rain tight)
Communication
Protocol
RTU (Modbus RTU), BAC (BACnet MS/TP), EZ7
Current Sensors/
Options
KIT (Split Core), SCS (Solid-Core), -SP (Single or Two Phase -
2 element)
Input Voltage
Configuration
3-wire (delta) Or 4-wire (wye)
Mains Voltage
Input
Up To 600 VAC RMS available
Input Power 6 VA maximum rating
Current Sensor
Rating
Up To 3200 amps RMS AC available
Power Factor 0.5 leading or lagging
Line Frequency 50-60 Hz
Metering Accuracy ANSI C12.20
62-0397_C.fm Page 7 Wednesday, May 9, 2018 9:28 AM
