E-MON CLASS 3200 METER
3 62-0397—02
1.0 INTRODUCTION
The Honeywell E-Mon Class 3200 meter is a 3-element meter with
communications. The device is used to monitor electric power usage of individual
loads after the utility meter and store kW and kVAR data for automatic meter
reading. Installation must only be performed by qualified personnel and in
accordance with these instructions and all applicable local and national electrical
codes. Honeywell E-Mon and its representatives assume no responsibility for
damages or injury resulting from the improper installation of this meter.
Verify the input voltage rating and configuration on the unit panel label to ensure
that it is suitable for the intended electrical service. For example, E-Mon Class
3200 meters labeled for 120/208V service MUST NOT be installed on service
feeds of 277/480 volts or 347/600 and vice versa.
Verify that the E-Mon Class 3200 meter’s current sensors are sized suitably for
the load to be monitored. Compare the color of the arrows on the current sensors
to the chart below to confirm the correct current sensor is being used.
Meter Labeled: Works On:
120V 120V, Single Phase
120/240V 120/240V, Single Phase
277V 277V, Single Phase
208V 208V, Three Phase
240V 240V, Three Phase
400V (380V,415V) 400V, Three Phase
480V 480V, Three Phase
600V 600V, Three Phase
Sensor Arrow Color Code Sensor Rating
Brown 100 A
Red 200 A
Yellow 400 A
Black 800 A
Blue 1600 A
White/Black 3200 A
62-0397_C.fm Page 3 Wednesday, May 9, 2018 9:28 AM
