Planning Excel 800
EN1B-0375GE51 R0910
12
XW885 Cable Details
12
3678
4
5
RJ45 plug with clip at front
RS232 plug
sub-D female
1
5
4
3
2
9
8
7
6
SHIELD
XW885
R
x
D
G
N
D
R
T
S
+5V
T
x
D
Fig. 7 XCL8010/laptop cable details
XW582 Cable Details
to XC5010C
1
5
4
3
2
9
8
7
6
XW582
SHIELD
R
x
D
G
N
D
+
5
V
E
T
x
D
Y
E
L
L
O
W
B
R
O
W
N
G
R
E
E
N
W
H
I
T
E
1
4
3
2
XI582
WIRING
TERMINALS
LOOSE
ENDS
Fig. 8 XW582 cable details
XW585 Cable Details
1
5
4
3
2
9
8
7
6
1
5
4
3
2
9
8
7
6
XW585
SHIELD
+5V
R
x
D
G
N
D
R
T
S
T
x
D
RS232 plug
sub-D female
RS232 plug
sub-D female
Fig. 9 XW585 cable details
XW586 Cable Details
1
5
4
3
2
9
8
7
6
12
3678
4
5
RS232 plug
sub-D male
SHIELD
D
C
D
D
S
R
R
x
D
R
T
S
T
x
D
C
T
S
D
T
R
G
N
D
XW586
RJ45 plug with clip at front
+5V
Fig. 10 XW586 cable details
LONWORKS Bus Termination Modules
Type Description
209541 LONWORKS Bus termination module
XAL-Term
L
ONWORKS connection and
termination module, which can be
mounted on DIN rails and in fuse
boxes
Table 15 LONWORKS Bus termination modules
Cable Specifications
Power Supply Cables
When checking the length of the power supply cable, the
connection cables to all I/O modules must be taken into
account.
Max. length 3 m (per side of the controller),
see Fig. 33 on page 25
Cross section
min. 0.75 mm
2
(AWG 18)
Table 16 Power supply cables specification
Panel Bus Cables
Max. length
40 m
Cable type
twisted pair, e.g., J-Y-Y 2 x 2 x 0.8
Table 17 Panel Bus cables specification
