Honeywell H Series User Manual

H-SERIES GREEN CLASS NET METER
5 62-0424-02
2.0 INTERNAL ELECTRONIC ASSEMBLIES
The unit is comprised of two major subassembly boards, the main power board and
the display board. Both circuit boards are mounted inside either a JIC STEEL
Enclosure.
Fig. 1. Internal Electronic Assemblies.
MAIN POWER
BOARD
DISPLAY
BOARD
M33270
