Honeywell HCE80 Mounting And Operation Manual

Appendix
28
Appendix
Navigation and function overview
Function Press button
Status LED
Zone LED Exit mode
Normal mode Lights up green
= Valve open
LED off = Valve closed
Binding
> 2 s
Lights up orange Flashing 4min after last action
Delete assigned
devices
Mode > 4 s in
binding mode
Lights up orange Zone LED extinguishes 4min after last action
Device display
> 2 s
Flashing orange Red = Room actual value
Green = Room
setpoint value
Orange = Room actual
value/room setpoint value
Automatically after 60s
or
Press other button
Cooling mode
Mode > 4 s
Press the button
in order to activate/
de-activate the
cooling mode
Green = Cooling
mode active
Red = Cooling
mode inactive
Red = Cooling active
and cooling contact
open (Cl. 3 and 4)
Green = Cooling active
and cooling contact
closed (Cl. 3 and 4)
Automatically after 60s
or
Press the Mode button
Send test signal
Keep and Mode
pressed for 4 s
Flashing green Light up red when the
test signal is sent
Automatically after
10minutes
or
Press other button
Receive test signal Flashing green Signal strength of the
assigned device is
indicated by flashing of the
respective green zone LED:
1x = Signal sufficient
5x = Signal strong
10s after last
received test signal
Communica-
tion error
LED lights up red
Flashing red = Room
actual value error
Flashing green = Room
setpoint value error
Flashing orange =
Room actual value/room
setpoint value error
When error has
been eliminated
Antenna error
LED flashes red
When error has
been eliminated
Reset all settings
Keep and Mode
pressed for 10 s
Flashing orange Release button
