Honeywell HON R100NG Series User Manual

Description
UsermanualforHONR100gaspressureregulatorwithHONP095NGpilot  15
TheHON P095NGpilotismadeupofthefollowingcomponentsandhousingparts:
Figure No. Description
1 Springdomehousing
2 Upperdiaphragmunit
3 Controlstagehousing
4 Lowerdiaphragmunit
5 Upstreampressurestagehousing

TheHON P095NGpilotfeaturesthefollowingfittings:
Figure No. Connection
1 Outletpressure(measuringline)
2 Outletpressure(discharging)
3 Pressuregauge(loadingpressure)
4 Inletpressure
5 Motorizationpressure(actuatorassembly)
6 Ventline(ambientpressurecompensation)

Pilotcomponents
Pilotfittings
