Maintenance
UsermanualforHONR100gaspressureregulatorwithHONP095NGpilot 49
Figure Step Description
5
Unscrewthethreadedjointsonthe
connectionflange.Makesuretofollowa
criss‐crosssequencewhendoingso.
5
Removetheactuatorassemblyfromthe
regulatinglineandremovetheflange
gaskets(1,2).
6
Slowlyandcarefullytransporttheactuator
assembly.
