Maintenance
UsermanualforHONR100gaspressureregulatorwithHONP095NGpilot  48
Proceedasfollows:
Figure Step Description
1
Removethepilot’smotorizationline(1),
outletpressure measuringline (2),outlet
pressuredischargingline (3),andinlet
pressureline(4).
2
Removetheconnectingplate(1)between
thepilotandtheactuatorassembly.

Beforeyoucanremovetheactuatorassembly,youmustfirstremovethepilot.

Proceedasfollows:
Figure Step Description
1
Removetheactuatorassembly’soutlet
pressureline(1)andoutletpressure
feedbackline(2).
2
Ifthereisone,disconnecttheelectrical
connectionfortheremotecontrolindica‐
tor.
3
Stabilizetheactuatorassemblyinits
installationpositionwithoutusingthe
fittingstodoso.
4 Rigtheslingstotheeyebolt(1).
Removingthepilot
Removingtheactuator
assembly
