UsermanualforHONR100gaspressureregulatorwithHONP095NGpilot  66

Observethefollowingcleaninginstructions:

 Beforeassembly,allpartsmustbecleanedinordertoremoveanyforeignparticles

(swarf)andsoiling.

 Ifscrews,bolts,orwashersarereplacedwithidenticalnewparts,anyoilonthesenew

partsmustfirstberemoved.



Observethetighteningtorquesbelowwhenfollowingtheinstructionsinthissection:

Part Tighteningtorque Step

Screws

24 Nm 26

Screws

47 Nm 40



Proceedasfollows:

Figure Step Description

1

Unscrewthecap(1).

2

Unscrewthesetscrew,includingthehex

nut.

3

Unscrewthelocknut(1).Removethelock

nut.

4

Removethespringplate(1)andthe

compressionspring(2).

Cleaning

Tighteningtorques

Maintainingthe

HON P095NG‐MPpilot
