Honeywell HON R100NG Series User Manual

Maintenance
UsermanualforHONR100gaspressureregulatorwithHONP095NGpilot  67
Figure Step Description
5
Unscrewthespringhousing’sscrews(1)in
acriss‐crosssequence.Removethespring
housing.
6 Removethediaphragmunit(1).
7
Turnthepilotover.Important!Thevalve
rodandthevalverod’scompressionspring
mayfallout.Setthemasideiftheydo.
Unscrewthecap(1).
8 Removetheretainingring(1).
9 Unscrewthestabilizerseat(1).
