Honeywell HON R100NG Series User Manual

Maintenance
UsermanualforHONR100gaspressureregulatorwithHONP095NGpilot  68
Figure Step Description
10
Unscrewthescrews(1)atthebottomof
thepilot.Removetheupstreampressure
stagehousing.
11
Removethelowerdiaphragmunit(1),
includingthecompressionspring,fromthe
upstreampressurestagehousing.
12 Loosentheguide(1).Removetheguide.
13
Removethefilter(1).Replacethefilter
withanewone.
14
Taketheguide.Replacetheguide’sO‐rings
(1,2)withnew,lubricatedO‐rings.
