Honeywell IntelliPath Series User Manual

LTE-I Installation and Setup Guide
24
PROMPTS OPTIONS DESCRIPTION
37
Invert Zn6 Y/N
(N)_
[Y], [N]
Inverts the alarm and normal states of the zone 6 trigger; otherwise
uses normal input signal.
38
Restore Zn6 Y/N
(Y)_
[Y], [N]
Enables restore reporting for zone 6.
39
Delay Zn6 (secs)
(00)_
[01-15]
[00] = no delay
Defines the reporting delay in seconds for zone 6.
UL/ULC: Must be set to 00.
40
Enable Zn7 Y/N
(N)_
[Y], [N]
Enables alarm reporting for zone 7.
If [N], skip to Prompt 45: "Use DHCP."
41
Zn7 Trigger Type
(V+)_
 (V+)
 (V–)
 (EOLR)
Selects the triggering method for this zone input.
Press the [space] key to scroll choices.
UL/ULC: V+ must be set as inverted and V– as
non-inverted.
42
Invert Zn7 Y/N
(N)_
[Y], [N]
Inverts the alarm and normal states of the zone 7 trigger; otherwise,
uses normal input signal.
43
Restore Zn7 Y/N
(Y)_
[Y], [N]
Enables restore reporting for zone 7.
44
Delay Zn7 (secs)
(00)_
[01-15]
[00] = no delay
Defines the reporting delay in seconds for zone 7.
UL/ULC: Must be set to 00.
Prompts 45-51 appear only if communication path includes IP.
45
Use DHCP Y/N
(Y)_
[Y], [N]
Dynamically allocates the IP addresses (recommended); then skip to
Prompt 50: "Enable Pwr Save".
If [N], uses fixed IP addresses.
46
NIC IP Address:
255.255.255.255_
12 digit:
xxx.xxx.xxx.xxx
Enter the 4-part address for this device. The 4 parts of the address
must be separated by spaces (displayed as periods in Review mode).
47
Subnet Mask:
255.255.255.255_
12 digit:
xxx.xxx.xxx.xxx
Enter the 32-bit address mask used to indicate the portion (bits) of the
IP address that is being used for the subnet address. The 4 parts of the
address must be separated by spaces (displayed as periods in Review
mode).
48
Gateway IP Addr:
255.255.255.255_
12 digit:
xxx.xxx.xxx.xxx
Enter the 4-part address assigned to the Gateway. The 4 parts of the
address must be separated by spaces (displayed as periods in Review
mode).
49
DNS Serv IP Addr:
255.255.255.255_
12 digit:
xxx.xxx.xxx.xxx
Enter the 4-part IP address assigned to the DNS (Domain Name
System) server. The 4 parts of the address must be separated by
spaces (displayed as periods in Review mode).
50
Enable Pwr Save
(N)_
[Y], [N] To meet the 24 hour UL battery backup requirement, choose "Y" to
enable this feature. If this causes connectivity problems with certain
routers or switches, then choose "N" and wire the communicator so it is
plugged into a UL listed UPS.
UL: Must be set to Y.
