Section 1: General Information
5
Specifications
Mechanical:
Dimensions: 8.4" x 8.0" x 1.5" Weight: 2.4 lbs., with battery
Input Power:
16.5VAC, 40VA transformer, or for ULC installations 12VDC from the
control panel.
(Honeywell transformer # 1361-GT included with LTE-I.)
(Honeywell transformer # 1361CN-GT not included with the LTE-I.)
Current Drain:
90mA (rms) standby, 125mA (rms) active
Backup Battery:
6V, 3.1AH, (Honeywell # K14139 included with LTE-I only.)
Expected Battery Life: 5 Years (approx.)
Note: The sealed lead acid battery used for backup will have reduced
life expectancy when exposed to elevated temperatures. The useful life
of the battery at 25ºC (77ºF) is approximately 4 years. At 35ºC (95ºF)
this will drop to 2 years and at 45ºC (113ºF) 1 year. Battery life
expectancy should be taken into account when locating the radio.
Fault Relay Output:
Open collector, 12VDC, 0.25W max.
Positive Trigger
Level:
6V or greater = positive trigger. (4V or less = restore.)
Negative Trigger
Level:
4V or less = negative trigger. (6V or greater = restore.)
Ethernet:
Network Standard: IEEE 802.3u compliant
Data Rate: 10Base-T / 100Base-T with auto detect
Ethernet Cable: Cat. 5 (min), MDI / MDI-X auto crossover
Environmental:
Operating temperature: –20º to +55ºC, for UL/ULC installations 0ºC to
+49ºC
Storage temperature: –40º to +70ºC
Humidity: 0 to 95% relative humidity, non-condensing
for UL installations 0% to 85%; for ULC installations 0% to 93%
Altitude: to 10,000 ft. operating, to 40,000 ft. storage
Frequency Bands
LTE
Band 2
LTE
Band 4
LTE
Band 5
LTE
Band 12
LTE
Band 13
WCDMA
Band II
WCDMA
Band V
LTE-IV X X X
LTE-IA X X X X X X X
LTE-IC X X X X X X X
Output Power
LTE, Class 3 23dBm
WCDMA Class 3 24dBm
