MeshGuard User’s Guide
10
3.2 Specifications
RF Certifications
FCC Part15
CE EN 300328
SRRC (Pending)
Wireless Approval For UAE In Middle East (TRA
REGISTERED No: ER36063/14
DEALER No: HONEYWELL INTERNATIONAL MIDDLE
EAST - LTD - DUBAI BR
Wireless Approval for QATAR In Middle East
ictQATAR Type Approval Reg. No.: R-4465
Display
Customized LCD (1 x 1.5″) with backlight
Audible alarm
90dB @ 30cm
Visual alarm
2 super-bright red LEDs
Calibration
Two-point field calibration
RF
IEEE 802.15.4/Zigbee with mesh stack
Operating Range
Up to 300 meters, line of sight
Transmission
Power
Up to 18dBm (63mw EIRP)
Receiver
Sensitivity
Minimum -95dBm at 2.4GHz
User Interface
Three keys (Y/+, MODE, N/-)
Power Supply
D-size EVE or Xeno Lithium primary battery, +3.6V, 19 Ah
Max Current
Consumption
200mA@3.6V during transmission
<0.5mA@3.6V during standby
Operation Time
Internal Battery:
For STD* Mode: up to 6 Months
For RTR** Mode: up to 10 days
*STD is standard-function device
**RTR is router-function device
Operating
Temperature
-40° to 122° F (-40° to +50° C) for CO, and H
2
S sensors
Other sensors: -4° to 122° F (-20° to +50° C)
Humidity
0% to 95% relative humidity, non-condensing
Dimensions
Metal Enclosure: 15.7cm x 9.3cm x 5.1cm
(6.2” x 3.7” x 2.0”)
Plastic Enclosure: 26.5cm x 9.5cm x 5.5cm
(10.5″ x 3.7″ x 2.1″)
Weight
Metal Enclosure: 1.2 kg (2.65 lbs)
Plastic Enclosure: 0.6 kg (1.3 lbs)
Package
IP-65
Mounting
Optional stainless-steel bracket mount or magnetic mount
Radio Specifications
Radio model: RM2400A
RF power(Tx): 20dBm
Frequency range: 2.400-2.4835GHz
Data rate: 250kbps
Modulation: 802.15.4 DSSS BPSK
